The 760' model is the biggest size version of Dovre's Classic' bestseller. The stove comes with a single air control and has a direct outside air connection and a side loading door.
“ PRODUCT NAME: 760WD
“ FAMILY: CLASSIC 540/640/760
“ COLOR: Black
“ TYPE: Stove
“ STYLE: Classic
“ DIMENSIONS WXHXD (MM): 780x800x565
“ WEIGHT (KG): 190
“ FUEL: Wood
“ CONNECTION DIAMETER (MM): 150
“ HEIGHT FLUE (MM): 645
“ CONNECTION PLACE: on top or rear
“ NOMINAL OUTPUT (KW): 12
“ MINIMAL OUTPUT (KW): 4
“ MAXIMUM PERFORMANCE (KW): kW14
“ CAPACITY (M³): 240
“ EFFICIENCY: 80,00%
“ CO EMISSIONS (13% O2): 0,06
“ DUST PARTICLES (MG/NM³): 39,5
“ COMBUSTION FLOOR: Refractory bottom with ash hatch
“ MINIMUM PRESSION: 12
“ FLUE GAS VOLUME (G/S): 10,4
“ LENGTH OF LOGS (CM): 55
“ SECOND COMBUSTION: Yes
“ ASH TRAY: Inclusive
“ HEAT SHIELD: Optional
“ OUTSIDE AIR: Inclusive
“ AVAILABLE IN COUNTRIES: Australia
“ TEMPERATURE INCREASE MEASURED IN THE MEASUREMENT SECTION (K): 270
“ NOX EMISSIONS (13%O2 AT NOMINAL HEAT OUTPUT - MG/NM³): 46
“ SEASONAL SPACE HEATING ENERGY EFFICIENCY (%): 70
“ DIRECT HEAT OUTPUT (KW): 12
“ INDIRECT HEAT OUTPUT (KW): 0
“ TYPE OF HEAT OUTPUT/ROOM TEMPERATURE CONTROL: single stage heat output, no room temperature control
“ FAMILY: CLASSIC 540/640/760
“ COLOR: Black
“ TYPE: Stove
“ STYLE: Classic
“ DIMENSIONS WXHXD (MM): 780x800x565
“ WEIGHT (KG): 190
“ FUEL: Wood
“ CONNECTION DIAMETER (MM): 150
“ HEIGHT FLUE (MM): 645
“ CONNECTION PLACE: on top or rear
“ NOMINAL OUTPUT (KW): 12
“ MINIMAL OUTPUT (KW): 4
“ MAXIMUM PERFORMANCE (KW): kW14
“ CAPACITY (M³): 240
“ EFFICIENCY: 80,00%
“ CO EMISSIONS (13% O2): 0,06
“ DUST PARTICLES (MG/NM³): 39,5
“ COMBUSTION FLOOR: Refractory bottom with ash hatch
“ MINIMUM PRESSION: 12
“ FLUE GAS VOLUME (G/S): 10,4
“ LENGTH OF LOGS (CM): 55
“ SECOND COMBUSTION: Yes
“ ASH TRAY: Inclusive
“ HEAT SHIELD: Optional
“ OUTSIDE AIR: Inclusive
“ AVAILABLE IN COUNTRIES: Australia
“ TEMPERATURE INCREASE MEASURED IN THE MEASUREMENT SECTION (K): 270
“ NOX EMISSIONS (13%O2 AT NOMINAL HEAT OUTPUT - MG/NM³): 46
“ SEASONAL SPACE HEATING ENERGY EFFICIENCY (%): 70
“ DIRECT HEAT OUTPUT (KW): 12
“ INDIRECT HEAT OUTPUT (KW): 0
“ TYPE OF HEAT OUTPUT/ROOM TEMPERATURE CONTROL: single stage heat output, no room temperature control
Specifications
More
Less
More
Less
Lead times, Assembly and Delivery
More
Less
More
Less
Current lead times are approximately 4-6 weeks. Assembly is free in the Riverina Region. Interstate delivery is free to your nearest capital city depot.
Description
The 760' model is the biggest size version of Dovre's Classic' bestseller. The stove comes with a single air control and has a direct outside air connection and a side loading door.
“ PRODUCT NAME: 760WD
“ FAMILY: CLASSIC 540/640/760
“ COLOR: Black
“ TYPE: Stove
“ STYLE: Classic
“ DIMENSIONS WXHXD (MM): 780x800x565
“ WEIGHT (KG): 190
“ FUEL: Wood
“ CONNECTION DIAMETER (MM): 150
“ HEIGHT FLUE (MM): 645
“ CONNECTION PLACE: on top or rear
“ NOMINAL OUTPUT (KW): 12
“ MINIMAL OUTPUT (KW): 4
“ MAXIMUM PERFORMANCE (KW): kW14
“ CAPACITY (M³): 240
“ EFFICIENCY: 80,00%
“ CO EMISSIONS (13% O2): 0,06
“ DUST PARTICLES (MG/NM³): 39,5
“ COMBUSTION FLOOR: Refractory bottom with ash hatch
“ MINIMUM PRESSION: 12
“ FLUE GAS VOLUME (G/S): 10,4
“ LENGTH OF LOGS (CM): 55
“ SECOND COMBUSTION: Yes
“ ASH TRAY: Inclusive
“ HEAT SHIELD: Optional
“ OUTSIDE AIR: Inclusive
“ AVAILABLE IN COUNTRIES: Australia
“ TEMPERATURE INCREASE MEASURED IN THE MEASUREMENT SECTION (K): 270
“ NOX EMISSIONS (13%O2 AT NOMINAL HEAT OUTPUT - MG/NM³): 46
“ SEASONAL SPACE HEATING ENERGY EFFICIENCY (%): 70
“ DIRECT HEAT OUTPUT (KW): 12
“ INDIRECT HEAT OUTPUT (KW): 0
“ TYPE OF HEAT OUTPUT/ROOM TEMPERATURE CONTROL: single stage heat output, no room temperature control
“ FAMILY: CLASSIC 540/640/760
“ COLOR: Black
“ TYPE: Stove
“ STYLE: Classic
“ DIMENSIONS WXHXD (MM): 780x800x565
“ WEIGHT (KG): 190
“ FUEL: Wood
“ CONNECTION DIAMETER (MM): 150
“ HEIGHT FLUE (MM): 645
“ CONNECTION PLACE: on top or rear
“ NOMINAL OUTPUT (KW): 12
“ MINIMAL OUTPUT (KW): 4
“ MAXIMUM PERFORMANCE (KW): kW14
“ CAPACITY (M³): 240
“ EFFICIENCY: 80,00%
“ CO EMISSIONS (13% O2): 0,06
“ DUST PARTICLES (MG/NM³): 39,5
“ COMBUSTION FLOOR: Refractory bottom with ash hatch
“ MINIMUM PRESSION: 12
“ FLUE GAS VOLUME (G/S): 10,4
“ LENGTH OF LOGS (CM): 55
“ SECOND COMBUSTION: Yes
“ ASH TRAY: Inclusive
“ HEAT SHIELD: Optional
“ OUTSIDE AIR: Inclusive
“ AVAILABLE IN COUNTRIES: Australia
“ TEMPERATURE INCREASE MEASURED IN THE MEASUREMENT SECTION (K): 270
“ NOX EMISSIONS (13%O2 AT NOMINAL HEAT OUTPUT - MG/NM³): 46
“ SEASONAL SPACE HEATING ENERGY EFFICIENCY (%): 70
“ DIRECT HEAT OUTPUT (KW): 12
“ INDIRECT HEAT OUTPUT (KW): 0
“ TYPE OF HEAT OUTPUT/ROOM TEMPERATURE CONTROL: single stage heat output, no room temperature control
Specifications
Lead times, Assembly and Delivery
Current lead times are approximately 4-6 weeks. Assembly is free in the Riverina Region. Interstate delivery is free to your nearest capital city depot.
